Diamond Cutting Disc for Porcelain | Continuous Rim

This sintered continuous rim diamond cutting disc is designed for high-precision wet cutting on equipment such as angle grinders, tile saws, and masonry saws. It produces smooth, chip-free cuts on brittle materials including ceramic, porcelain, marble, and glass. The disc's design minimizes material waste and ensures a clean finish, making it suitable for professional applications requiring consistent results. The sintered diamond matrix delivers consistent edge quality and stable performance. This manufacturing method provides extended tool life, reducing the frequency of disc changes and operational downtime.

105–300 mmTile saw and grinder sizes for precision wet cutting

Chip-FreeSmooth, chip-free cuts on ceramic, porcelain, marble and sintered stone

Wet + DryPrecision cutting on tile saws, angle grinders and masonry saws

Applicable Materials

Ceramic tile, porcelain, marble, granite and sintered stone

Certifications & Credentials

CE Certified · ISO 9001:2015 · Industry Standard Drafting Participant · 120+ Countries & Regions Served

Get a Custom Quote

Dinosaw machine Sintered Continuous Rim Diamond Cutting Disc for Tile

Applications Performance Specs Technology Comparison Manufacturing Support FAQ

Compatible Materials & Products

Precision cutting for premium finishes on brittle materials.

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (2)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (22)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (21)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (20)@1.5x

Ceramic Tile > Clean wet saw cutting

Cutting standard ceramic tile demands a clean edge for tight grout lines. Aggressive discs can easily chip the glazed surface, leading to rework and wasted material, especially during repetitive cuts on a tile saw or circular saw. The sintered continuous rim provides a gentle yet effective cutting action. Its uniform diamond distribution ensures a consistent abrasion process. When used with water, it continuously clears debris and prevents overheating, preserving both the disc and the tile glaze. This disc delivers consistently clean cuts, improving installation speed and finish quality. It reduces tile breakage, lowers project costs, and produces a smooth edge that simplifies grouting and ensures a superior final look.

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (29)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (32)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (31)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (30)@1.5x

Marble > Fine edge trimming

Marble is a relatively soft stone susceptible to fracturing and edge chipping during final trimming. Precision is paramount, as any imperfections on expensive slabs can detract from the luxury finish. Our cutting disc's continuous rim and high-concentration diamond formula are engineered for delicate materials. The sintered bond ensures diamonds are securely held, providing a stable and smooth cutting pass that minimizes vibration and impact. Achieve razor-sharp, clean edges on marble countertops and tiles. This disc reduces the risk of costly material damage and significantly lessens the time required for subsequent edge polishing, improving fabrication efficiency.

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (24)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (26)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (27)@1.5x

Diamond Cutting Disc for Porcelain Continuous Rim DINOSAW (28)@1.5x

Sintered Stone > Low-chipping finish

Sintered stone is ultra-compact and hard, making it challenging to cut without chipping. The material’s internal stresses require a highly stable cutting disc that can withstand intense abrasion while maintaining a clean cutting path on a masonry saw. Our continuous rim disc features a rigid steel core and a durable sintered bond designed for hard materials. The uniform diamond exposure along the rim provides consistent cutting power, preventing deflection and edge damage. Wet cutting is mandatory to manage heat. Produce clean, low-chipping cuts on demanding sintered stone surfaces. This improves fabrication quality, reduces waste of expensive materials, and ensures finished panels meet the highest visual and structural standards.

Real Cutting Performance & Key Metrics

The DINOSAW sintered continuous rim disc is built for precision: chip-free cuts on ceramic, porcelain, marble and sintered stone through 105–300 mm sizes for tile saws, angle grinders and masonry saws — the disc for edges that show.

105–300 mm

Precision Range

Nine diameters from 105 to 300 mm cover tile saws, grinders and masonry saws — the full precision cutting fleet.

Chip-Free Edge

Finish Quality

The continuous rim shears brittle material without segment impact: cut edges install directly or need only one polishing pass.

Sintered Rim

Rim Durability

Sintered rim construction holds diamond through the rim depth, not a surface layer — the rim wears evenly and stays true to diameter.

Wet + Dry

Saw Flexibility

Runs on wet tile saws and dry grinders alike — tile crews and stone shops stock one disc for both regimes.

Applicable materials: Ceramic tile, porcelain, marble, granite and sintered stone.

Typical tools: Tile saws, angle grinders and masonry saws for finish cutting, edge trimming and detail work.

Actual disc life varies with material hardness and wet versus dry cutting conditions.

Specs and options

Nine diameters from 105 mm (2 mm kerf) to 300 mm (2.8 mm kerf) with arbor options 20/22.23/25.4 mm: continuous sintered rims sized for chip-sensitive cutting on tile saws down to handheld trim work.

Diameter	Diameter	Segment Width	Segment Height	Arbor
Inches	mm	mm	mm	mm
4.13"	105	2	10	20
4.5"	115	2	10	20
5"	125	2.2	10	20
6"	150	2.4	10	20
7"	180	2.6	10	22.23
8"	200	2.6	10	25.4
9"	230	2.8	10	25.4
10"	250	2.8	10	25.4
12"	300	3	10	25.4

Core Technology & Disc Structure

Four engineering decisions behind the continuous rim design. The numbered points on the disc diagram correspond to the systems below.

Continuous Rim Disc Selection Workflow

Match the disc in four steps: confirm the saw type and arbor, select diameter for the cut capacity, run wet on tile saws for best life and finish, then feed steadily without forcing — porcelain rewards patience with chip-free edges.

Continuous Shear Edge

Without segment gaps, the rim meets the material as a continuous shearing edge: porcelain and ceramic cut without the micro-impact chips that segment lips leave at the surface.

Sintered Rim Depth

Sintered rims carry diamond through the full rim section, not a plated surface: as the rim wears it keeps cutting — disc life is measured by rim depth, not by when the coating fades.

Brittle-Material Geometry

Kerf width scales with diameter from 2.0 to 2.8 mm: fine slots on trimming sizes, stable tracking on tile saw sizes — the geometry follows the tool, not a single compromise.

Multi-Arbor Options

20, 22.23 and 25.4 mm arbor options by size match tile saws and grinders directly — concentric seating without adapters protects the chip-free edge quality the disc exists to deliver.

Wet Cutting Efficiency

On wet tile saws the continuous rim works with full water flow: cooling at the shear zone extends both disc life and edge quality on long porcelain runs.

Diameter Precision Scaling

From 105 mm grinder trims to 300 mm tile saw cuts, one rim design logic covers the precision range — crews learn one disc behavior across the fleet.

Sintered Continuous Rim vs. Plated Rim Discs

A construction comparison for tile and finish cutting buyers.

Sintered Continuous Rim vs. Plated Rim Discs
Plated Rim Disc	VS	Sintered Rim
Surface plating only	Diamond layer	✓ Diamond through rim depth
Weeks until coating fades	Life measure	✓ Linear meters until rim consumed
Degrades as coating wears	Edge consistency	✓ Consistent to end of life
Chips when plating fails	Chip behavior	✓ Chip-free while rim lasts
Occasional DIY use	Best for	✓ Production tile & stone cutting

Note: configurations vary by brand and model; actual performance depends on the specific machine, material and working conditions.

The Manufacturer Behind the Disc Range

DINOSAW is a manufacturer of CNC stone processing machinery, specializing in diamond wire saw machines and CNC stone cutting equipment. With more than 20 years of R&D and manufacturing experience, DINOSAW contributes to industry standards including T/CMES 41001-2025 for CNC wire saw machines, holds 100+ technical patents, and supplies equipment and technical support to customers in 120+ countries and regions. Its manufacturing and management systems are certified to ISO 9001, ISO 14001 and ISO 45001, with CE-compliant machinery for international markets.

DINOSAW CNC stone machinery manufacturing workshop

DINOSAW R&D & ManufacturingMechanical Design · CNC Control Development · Assembly · Testing · Commissioning · Global Delivery

Industry Standard Drafting

DINOSAW contributes to industry standards for stone machinery, including T/CMES 41001-2025 for CNC wire saw machines, as well as standards covering multi-wire saws, combined wire saw machines and five-axis bridge cutting equipment. This work reflects the company’s long-term involvement in machine design, manufacturing, testing and quality control.

20+Years of Stone Machinery R&D & Manufacturing Experience

100+Technical Patents — Covering machine structures, CNC control, cutting systems and stone processing technologies

120+Countries & Regions Served — Equipment, installation and technical support worldwide

CE Compliance & ISO Management Systems

CE: Stone cutting machinery assessed against Machinery Directive 2006/42/EC and relevant EN standards.
ISO: Management systems certified to ISO 9001, ISO 14001 and ISO 45001.

Ordering Requirements & After-Sales Support

DINOSAW provides disc selection support and batch supply for tile and stone finish cutting.

Tool Fit20/22.23/25.4 mm arbors

Match arbor to saw or grinder spec.

RPM MatchDisc RPM ≥ tool RPM

Verify rated speed before mounting.

Wet CuttingRecommended where available

Water extends life and finish on porcelain.

01 · Pre-Shipment & DeliveryMachine configuration, packaging and transport requirements confirmed before dispatch, with factory inspection and documents verified.

02 · Installation & CommissioningOn-site utilities and foundation check, machine positioning, commissioning and acceptance.

03 · Operator TrainingHands-on training covering routine CNC operation and daily checks of blades, spindles, cooling and lubrication.

04 · After-Sales SupportRemote technical assistance, maintenance support and spare parts coordination throughout the machine's service life.

Continuous Rim Disc Selection & Use FAQ

Common Questions About Sintered Continuous Rim Discs

When a continuous rim chips porcelain, the cause is usually mechanical, not the rim design. Check in order: support under the tile — a poorly supported exit line lets the offcut drop and tear the edge, the single most common cause; feed pressure — forcing the cut flexes the tile and fractures the glaze line at the edge; blade wear — a rim worn past its useful life develops runout, and a wobbling rim chips exactly like a dull blade looks; and flange cleanliness — a chip of dried slurry between flange and disc induces the same wobble. Run the tile fully supported, feed steadily without pushing, and true the disc on the arbor before blaming the material. If the disc is new, properly mounted and the tile fully supported, and chips persist on one material brand only, the bond may be too hard for that body — that is a specification question for a trial cut.

Longer than any plated disc, and measurably: sintered rims carry abrasive depth, so life is a function of how much rim you use, not when a coating gives out. On a wet tile saw cutting standard ceramic, a quality sintered rim commonly serves through many production runs; on hard porcelain or granite, expect proportionally shorter life because the material wears the rim faster — the disc is doing the same job, against a harder opponent. Track linear meters per disc on your dominant material and use that as the baseline: when cut quality drops before the rim looks spent, the rim has glazed or the machine needs checking; when the rim is visibly consumed, the disc has delivered its full life. Either way, the sintered rim's depth is the reason the answer is measured in meters rather than in weeks.
